X-1569T
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy X-1569T with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy X-1569T with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | X-1569T |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | XFMR GATE DRIVE 1500VDC ISO |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Reference Price (In US Dollars) | 400 pcs | 800 pcs | 1200 pcs | ||
|---|---|---|---|---|---|
| $2.011 | $1.976 | $1.941 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | X-1569T | Manufacturer | Pulse Electronics Corporation |
|---|---|---|---|
| Description | XFMR GATE DRIVE 1500VDC ISO | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 17095 pcs | Data sheet | X-1569 Series DatasheetMilitary/Aerospace Product Guide |
| Category | Transformers | Weight | - |
| Turns Ratio - Primary:Secondary | 1:1:1 | Transformer Type | Gate Drive |
| Size / Dimension | 0.355" L x 0.340" W (9.01mm x 8.63mm) | Series | - |
| Packaging | Tape & Reel (TR) | Other Names | 1902-1056-2 |
| Operating Temperature | -40°C ~ 130°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | Manufacturer Standard Lead Time | 13 Weeks |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | Inductance | 3.3mH |
| Height - Seated (Max) | 0.300" (7.62mm) | Energy Time (E.T.) | 45.1V µS |
