PF0553.822NLT

PF0553.822NLT
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PF0553.822NLT with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number PF0553.822NLT
Manufacturer Pulse Electronics Corporation
Description INDUCT ARRAY 2 COIL 8.9UH SMD
Lead Free Status / RoHS Status Lead free / RoHS Compliant
In Stock 5500 pcs
Reference Price
(In US Dollars)		Get a quote

Submit a Request For Quotation on quantities greater than those displayed.

Target Price:(USD)
Quantity:
Total:
$0.00

Product parameter

Part Number PF0553.822NLT Manufacturer Pulse Electronics Corporation
Description INDUCT ARRAY 2 COIL 8.9UH SMD Lead Free Status / RoHS Status Lead free / RoHS Compliant
Quantity Available 5500 pcs Data sheet PF0552NL, PF0553NL Series
Category Inductors, Coils, Chokes Tolerance ±20%
Size / Dimension 0.492" L x 0.492" W (12.50mm x 12.50mm) Shielding Shielded
Series PF0553NL Ratings -
Packaging Tape & Reel (TR) Package / Case Nonstandard
Operating Temperature -40°C ~ 125°C Number of Coils 2
Mounting Type Surface Mount Moisture Sensitivity Level (MSL) 1 (Unlimited)
Lead Free Status / RoHS Status Lead free / RoHS Compliant Inductance - Connected In Series 35µH
Inductance - Connected In Parallel 8.9µH Height 0.315" (8.00mm)
Detailed Description Shielded 2 Coil Inductor Array 35µH Inductance - Connected in Series 8.9µH Inductance - Connected in Parallel 15 mOhm Max DC Resistance (DCR) - Parallel 6.2A Nonstandard DC Resistance (DCR) - Series 62 mOhm Max
DC Resistance (DCR) - Parallel 15 mOhm Max Current Saturation - Series 6.1A
Current Saturation - Parallel 12A Current Rating - Series 3.1A
Current Rating - Parallel 6.2A
