PA4341.821NLT
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PA4341.821NLT with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PA4341.821NLT with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | PA4341.821NLT |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | FIXED IND 820NH 13A 8 MOHM SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | 500 pcs | |
|---|---|---|---|---|---|
| $0.406 | $0.376 | $0.272 | $0.208 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | PA4341.821NLT | Manufacturer | Pulse Electronics Corporation |
|---|---|---|---|
| Description | FIXED IND 820NH 13A 8 MOHM SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 91405 pcs | Data sheet | PA4341NLT Series Datasheet |
| Category | Inductors, Coils, Chokes | Type | Molded |
| Tolerance | ±20% | Supplier Device Package | - |
| Size / Dimension | 0.299" L x 0.272" W (7.60mm x 6.90mm) | Shielding | Shielded |
| Series | PA4341.XXXNLT | Ratings | AEC-Q200 |
| Q @ Freq | - | Packaging | Original-Reel® |
| Package / Case | Nonstandard | Other Names | 553-3422-6 |
| Operating Temperature | -40°C ~ 125°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | - |
| Manufacturer Standard Lead Time | 15 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance Frequency - Test | 100kHz | Inductance | 820nH |
| Height - Seated (Max) | 0.118" (3.00mm) | Frequency - Self Resonant | - |
| Features | - | Detailed Description | 820nH Shielded Molded Inductor 13A 8 mOhm Max Nonstandard |
| DC Resistance (DCR) | 8 mOhm Max | Current Rating | 13A |
| Current - Saturation | 24A |
