PA0803NL
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PA0803NL with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PA0803NL with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | PA0803NL |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | XFMR DC/DC CONV SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 40 pcs | 80 pcs | |
|---|---|---|---|---|---|
| $3.708 | $2.841 | $2.407 | $2.367 | ||
| 120 pcs | 280 pcs | 520 pcs | 1000 pcs | ||
| $2.249 | $2.225 | $2.194 | $2.17 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | PA0803NL | Manufacturer | Pulse Electronics Corporation |
|---|---|---|---|
| Description | XFMR DC/DC CONV SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 17059 pcs | Data sheet | PA08xx(NL) Series |
| Category | Transformers | Voltage - Primary | 18 ~ 76V |
| Voltage - Isolation | 1500Vrms | Voltage - Auxiliary | - |
| Type | For DC/DC Converters | Style | Planar |
| Size / Dimension | 0.850" L x 0.920" W (21.60mm x 23.37mm) | Series | PA08XXNL |
| Other Names | 553-2906 | Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 15 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Intended Chipset | - | Inductance @ Frequency | - |
| Height - Seated (Max) | 0.348" (8.85mm) | Frequency | 200 ~ 700kHz |
| Footprint | 0.850" L x 0.920" W (21.60mm x 23.37mm) | Chipset Manufacturer | - |
| Applications | - |
