HDX8005NL
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy HDX8005NL with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy HDX8005NL with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | HDX8005NL |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | MDL,SIN, HDBASET, 100W, SMT |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 35 pcs | 70 pcs | |
|---|---|---|---|---|---|
| $3.445 | $2.639 | $2.236 | $2.199 | ||
| 105 pcs | 280 pcs | 525 pcs | 1015 pcs | ||
| $2.089 | $2.067 | $2.038 | $2.016 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | HDX8005NL | Manufacturer | Pulse Electronics Corporation |
|---|---|---|---|
| Description | MDL,SIN, HDBASET, 100W, SMT | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 15779 pcs | Data sheet | HDX8005NL Datasheet |
| Category | Transformers | Weight | - |
| Turns Ratio - Primary:Secondary | 1:1 | Transformer Type | HDBase-T |
| Series | - | Other Names | 1840-1291-5 |
| Operating Temperature | -40°C ~ 85°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 11 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance | 120µH |
| Height - Seated (Max) | 0.225" (5.72mm) | Energy Time (E.T.) | - |
