H5062FNL
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy H5062FNL with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy H5062FNL with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | H5062FNL |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | PULSE XFMR 1CT:1CT TX 1CT:1CT RX |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $2.504 | $1.901 | $1.851 | $1.701 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $1.601 | $1.551 | $1.501 | $1.451 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | H5062FNL | Manufacturer | Pulse Electronics Corporation |
|---|---|---|---|
| Description | PULSE XFMR 1CT:1CT TX 1CT:1CT RX | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 20989 pcs | Data sheet | H5062FNL Drawing |
| Category | Transformers | Weight | - |
| Turns Ratio - Primary:Secondary | 1CT:1CT Transmitter, 1CT:1CT Receiver | Transformer Type | LAN 10/100/1000 Base-T |
| Size / Dimension | 0.689" L x 0.600" W (17.50mm x 15.24mm) | Series | - |
| Other Names | 553-2235 | Operating Temperature | 0°C ~ 70°C |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 13 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance | 350µH | Height - Seated (Max) | 0.225" (5.72mm) |
| Energy Time (E.T.) | - |
