H2009FNL
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy H2009FNL with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy H2009FNL with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | H2009FNL |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | PULSE XFMR 1CT:1CT TX 1CT:1CT RX |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 35 pcs | 70 pcs | |
|---|---|---|---|---|---|
| $3.425 | $2.624 | $2.223 | $2.186 | ||
| 105 pcs | 280 pcs | 525 pcs | 1015 pcs | ||
| $2.077 | $2.055 | $2.026 | $2.004 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | H2009FNL | Manufacturer | Pulse Electronics Corporation |
|---|---|---|---|
| Description | PULSE XFMR 1CT:1CT TX 1CT:1CT RX | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 17288 pcs | Data sheet | H2009FNL Drawing |
| Category | Transformers | Weight | - |
| Turns Ratio - Primary:Secondary | 1CT:1CT Transmitter, 1CT:1CT Receiver | Transformer Type | LAN 10G Base-T |
| Size / Dimension | 0.518" L x 0.703" W (13.16mm x 17.86mm) | Series | - |
| Other Names | 553-2222 | Operating Temperature | 0°C ~ 70°C |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 14 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance | 350µH | Height - Seated (Max) | 0.241" (6.12mm) |
| Energy Time (E.T.) | - |
