H1012NL
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy H1012NL with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy H1012NL with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | H1012NL |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | MODULE TRANSFMR SNGL LAN 16P SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $2.081 | $1.687 | $1.364 | $1.277 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $1.22 | $1.184 | $1.148 | $1.112 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | H1012NL | Manufacturer | Pulse Electronics Corporation |
|---|---|---|---|
| Description | MODULE TRANSFMR SNGL LAN 16P SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 30110 pcs | Data sheet | 10/100 Base-T Single Port |
| Category | Transformers | Weight | 0.11 oz (3.13g) |
| Turns Ratio - Primary:Secondary | 1CT:1CT | Transformer Type | Isolation and Data Interface (Encapsulated) |
| Size / Dimension | 1.000" L x 0.390" W (25.40mm x 9.91mm) | Series | - |
| Packaging | Tube | Other Names | 553-1317 |
| Operating Temperature | 0°C ~ 70°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | Manufacturer Standard Lead Time | 13 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance | - |
| Height - Seated (Max) | 0.245" (6.22mm) | Energy Time (E.T.) | - |
