Home > Products > Transformers > Pulse Transformers > H1012

H1012

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy H1012 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	H1012
Manufacturer	Pulse Electronics Corporation
Description	MODULE TRANSFMR SNGL LAN 16P SMD
Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant

~~In Stock~~ 4146 pcs
Reference Price (In US Dollars)	Get a quote

Product parameter
Data sheet

Product parameter

Part Number	H1012	Manufacturer	Pulse Electronics Corporation
Description	MODULE TRANSFMR SNGL LAN 16P SMD	Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant
Quantity Available	4146 pcs	Data sheet	10/100 Base-T Single Port
Category	Transformers	Weight	0.11 oz (3.13g)
Turns Ratio - Primary:Secondary	1CT:1CT	Transformer Type	LAN
Size / Dimension	1.000" L x 0.390" W (25.40mm x 9.91mm)	Series	-
Packaging	Bulk	Other Names	553-1202
Operating Temperature	0°C ~ 70°C	Mounting Type	Surface Mount
Moisture Sensitivity Level (MSL)	4 (72 Hours)	Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant
Inductance	-	Height - Seated (Max)	0.245" (6.22mm)
Energy Time (E.T.)	-
