CM150DUS-12F
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy CM150DUS-12F with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy CM150DUS-12F with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | CM150DUS-12F |
|---|---|
| Manufacturer | Powerex, Inc. |
| Description | IGBT MOD DUAL 600V 150A F SER |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | CM150DUS-12F | Manufacturer | Powerex, Inc. |
|---|---|---|---|
| Description | IGBT MOD DUAL 600V 150A F SER | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5503 pcs | Data sheet | CM150DUS-12F |
| Category | Discrete Semiconductor Products | Voltage - Collector Emitter Breakdown (Max) | 600V |
| Vce(on) (Max) @ Vge, Ic | 2.7V @ 15V, 150A | Supplier Device Package | Module |
| Series | IGBTMOD™ | Power - Max | 520W |
| Package / Case | Module | Operating Temperature | -40°C ~ 150°C (TJ) |
| NTC Thermistor | No | Mounting Type | Chassis Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Input Capacitance (Cies) @ Vce | 41nF @ 10V | Input | Standard |
| IGBT Type | Trench | Detailed Description | IGBT Module Trench Half Bridge 600V 150A 520W Chassis Mount Module |
| Current - Collector Cutoff (Max) | 1mA | Current - Collector (Ic) (Max) | 150A |
| Configuration | Half Bridge |
