1830172
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1830172 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1830172 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1830172 |
|---|---|
| Manufacturer | Phoenix Contact |
| Description | TERM BLOCK HDR 18POS 3.81MM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 50 pcs | 100 pcs | |
|---|---|---|---|---|---|
| $4.572 | $4.447 | $4.156 | $3.823 | ||
| 250 pcs | 500 pcs | 1000 pcs | |||
| $3.532 | $3.366 | $3.158 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1830172 | Manufacturer | Phoenix Contact |
|---|---|---|---|
| Description | TERM BLOCK HDR 18POS 3.81MM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 10864 pcs | Data sheet | 1830172 Datasheet |
| Category | Connectors, Interconnects | Wire Strip Length | - |
| Wire Gauge or Range - mm² | - | Wire Gauge or Range - AWG | - |
| Voltage - UL | 300V | Voltage - IEC | 320V |
| Type | Header, Male Pins, Shrouded (4 Side) | Torque - Screw | - |
| Termination Style | Solder | Series | COMBICON MCD |
| Screw Size | - | Positions Per Level | 9 |
| Plug Wire Entry | - | Pitch | 0.150" (3.81mm) |
| Packaging | Bulk | Other Names | 1830172-ND 277-14135 MCD1,5/9-GF-3,81 MCD159GF381 |
| Operating Temperature | - | Number of Positions | 18 |
| Number of Levels | 2 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Manufacturer Standard Lead Time | 2 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insulation Height | 0.894" (22.71mm) | Ingress Protection | - |
| Housing Material | Polyamide (PA), Nylon | Header Orientation | 90°, Right Angle |
| Features | Board Guide, Mating Flange | Detailed Description | 18 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.150" (3.81mm) 90°, Right Angle Through Hole |
| Current - UL | 8A | Current - IEC | 8A |
| Contact Tail Length | 0.138" (3.50mm) | Contact Mating Finish | Tin |
| Contact Material | - | Color | Green |
