Home > Products > Connectors, Interconnects > Circular Connectors > 1524788

1524788

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1524788 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	1524788
Manufacturer	Phoenix Contact
Description	CONN RCPT FMALE 3POS GOLD SOLDER
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 8710 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	50 pcs	100 pcs	250 pcs
Reference Price (In US Dollars)	$5.617	$5.167	$4.774	$4.55	$4.269

Product parameter
Data sheet

Product parameter

Part Number	1524788	Manufacturer	Phoenix Contact
Description	CONN RCPT FMALE 3POS GOLD SOLDER	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	8710 pcs	Data sheet	1524788
Category	Connectors, Interconnects	Voltage Rating	50VAC, 60VDC
Termination	Solder	Shielding	-
Shell Size, MIL	-	Shell Size - Insert	M8-3
Shell Material	Brass	Shell Finish	Nickel
Series	DSIV	Packaging	Bulk
Other Names	1524788-ND 277-7284 SACC-DSIV-M 8FS-3CON-L 90 SACC-DSIV-M8FS-3CON-L90	Orientation	A
Operating Temperature	-25°C ~ 85°C	Number of Positions	3
Mounting Type	Panel Mount, Through Hole, Right Angle	Mounting Feature	Bulkhead
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Material Flammability Rating	UL94 HB
Manufacturer Standard Lead Time	2 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Insert Material	Polyamide (PA66), Nylon 6/6	Ingress Protection	IP67 - Dust Tight, Waterproof
Features	Board Guide, Board Lock	Fastening Type	Threaded
Detailed Description	3 Position Circular Connector Receptacle, Female Sockets Solder Gold	Current Rating	4A
Contact Material	Copper Tin	Contact Finish Thickness - Mating	-
Contact Finish - Mating	Gold	Connector Type	Receptacle, Female Sockets
Color	Black, Silver	Cable Opening	-
Backshell Material, Plating	-	Applications	-
