NC4D-JP-DC5V
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy NC4D-JP-DC5V with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy NC4D-JP-DC5V with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | NC4D-JP-DC5V |
|---|---|
| Manufacturer | Panasonic |
| Description | RELAY GENERAL PURPOSE 4PDT 5A 5V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 20 pcs | 40 pcs | 60 pcs | |
|---|---|---|---|---|---|
| $5.585 | $4.963 | $4.715 | $4.467 | ||
| 100 pcs | 260 pcs | 500 pcs | 1000 pcs | ||
| $4.219 | $3.847 | $3.598 | $3.412 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | NC4D-JP-DC5V | Manufacturer | Panasonic |
|---|---|---|---|
| Description | RELAY GENERAL PURPOSE 4PDT 5A 5V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 11351 pcs | Data sheet | NC Series |
| Category | Relays | Turn On Voltage (Max) | 4 VDC |
| Turn Off Voltage (Min) | 0.5 VDC | Termination Style | PC Pin |
| Switching Voltage | 250VAC - Max | Series | NC |
| Release Time | 10ms | Relay Type | General Purpose |
| Packaging | Tube | Other Names | 255-1937 NC4D-JP-DC5V-ND NC4DJPDC5V Q948458 |
| Operating Temperature | -40°C ~ 55°C | Operate Time | 20ms |
| Mounting Type | Through Hole | Manufacturer Standard Lead Time | 10 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Features | - |
| Detailed Description | General Purpose Relay 4PDT (4 Form C) 5VDC Coil Through Hole | Contact Rating (Current) | 5A |
| Contact Material | Silver Nickel (AgNi) | Contact Form | 4PDT (4 Form C) |
| Coil Voltage | 5VDC | Coil Type | Non Latching |
| Coil Resistance | 34.7 Ohms | Coil Power | 720 mW |
| Coil Current | 144mA |
This browser does not support inline PDFs. Please download the PDF to view it: Download PDF
