JC2AF-DC6V
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy JC2AF-DC6V with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy JC2AF-DC6V with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | JC2AF-DC6V |
|---|---|
| Manufacturer | Panasonic |
| Description | RELAY GEN PURPOSE DPST 10A 6V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | JC2AF-DC6V | Manufacturer | Panasonic |
|---|---|---|---|
| Description | RELAY GEN PURPOSE DPST 10A 6V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5849 pcs | Data sheet | JC Relays |
| Category | Relays | Turn On Voltage (Max) | 4.8 VDC |
| Turn Off Voltage (Min) | 0.6 VDC | Termination Style | PC Pin |
| Switching Voltage | 250VAC - Max | Series | JC |
| Release Time | 2ms | Relay Type | General Purpose |
| Packaging | Bulk | Operating Temperature | -50°C ~ 60°C |
| Operate Time | 15ms | Mounting Type | Through Hole |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Features | - |
| Detailed Description | General Purpose Relay DPST-NO (2 Form A) 6VDC Coil Through Hole | Contact Rating (Current) | 10A |
| Contact Material | Silver Alloy | Contact Form | DPST-NO (2 Form A) |
| Coil Voltage | 6VDC | Coil Type | Non Latching |
| Coil Resistance | 36 Ohms | Coil Power | 1 W |
| Coil Current | 167mA |
