HE1AN-Q-AC24V
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy HE1AN-Q-AC24V with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy HE1AN-Q-AC24V with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | HE1AN-Q-AC24V |
|---|---|
| Manufacturer | Panasonic |
| Description | RELAY GEN PURPOSE SPST 30A 24V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $8.375 | $7.956 | $7.537 | $7.119 | ||
| 100 pcs | 250 pcs | 500 pcs | |||
| $6.70 | $6.281 | $5.862 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | HE1AN-Q-AC24V | Manufacturer | Panasonic |
|---|---|---|---|
| Description | RELAY GEN PURPOSE SPST 30A 24V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 6648 pcs | Data sheet | HE Series Datasheet |
| Category | Relays | Turn On Voltage (Max) | 16.8 VAC |
| Turn Off Voltage (Min) | 3.6 VAC | Termination Style | Quick Connect - 0.250" (6.3mm) |
| Switching Voltage | 277VAC, 30VDC - Max | Series | HE |
| Release Time | 30ms | Relay Type | General Purpose |
| Packaging | Bulk | Other Names | 255-3707 HE1AN-Q-AC24V-ND HE1ANQAC24V |
| Operating Temperature | -50°C ~ 55°C | Operate Time | 30ms |
| Mounting Type | Chassis Mount | Manufacturer Standard Lead Time | 12 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Features | - |
| Detailed Description | General Purpose Relay SPST-NO (1 Form A) 24VAC Coil Chassis Mount | Contact Rating (Current) | 30A |
| Contact Material | Silver Tin Oxide (AgSnO) | Contact Form | SPST-NO (1 Form A) |
| Coil Voltage | 24VAC | Coil Type | Non Latching |
| Coil Power | 1.8 VA | Coil Current | 74.0mA |
