HE1AN-DC12V
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy HE1AN-DC12V with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy HE1AN-DC12V with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | HE1AN-DC12V |
|---|---|
| Manufacturer | Panasonic |
| Description | RELAY GEN PURPOSE SPST 30A 12V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $7.857 | $6.984 | $6.634 | $6.285 | ||
| 100 pcs | 250 pcs | 500 pcs | |||
| $5.936 | $5.412 | $5.063 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | HE1AN-DC12V | Manufacturer | Panasonic |
|---|---|---|---|
| Description | RELAY GEN PURPOSE SPST 30A 12V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 7170 pcs | Data sheet | HE Series Datasheet |
| Category | Relays | Turn On Voltage (Max) | 8.4 VDC |
| Turn Off Voltage (Min) | 1.2 VDC | Termination Style | Plug In, Quick Connect - 0.250" (6.3mm) |
| Switching Voltage | 277VAC, 30VDC - Max | Series | HE |
| Release Time | 10ms | Relay Type | General Purpose |
| Packaging | Bulk | Other Names | 255-1641 HE1ANDC12V |
| Operating Temperature | -50°C ~ 55°C | Operate Time | 30ms |
| Mounting Type | Chassis Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 12 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Features | - | Detailed Description | General Purpose Relay SPST-NO (1 Form A) 12VDC Coil Chassis Mount |
| Contact Rating (Current) | 30A | Contact Material | Silver Tin Oxide (AgSnO) |
| Contact Form | SPST-NO (1 Form A) | Coil Voltage | 12VDC |
| Coil Type | Non Latching | Coil Resistance | 75 Ohms |
| Coil Power | 1.92 W | Coil Current | 160mA |
