ELJ-LC2R2MF
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ELJ-LC2R2MF with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy ELJ-LC2R2MF with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ELJ-LC2R2MF |
|---|---|
| Manufacturer | Panasonic |
| Description | FIXED IND 2.2UH 520MA 330 MOHM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | ||||
|---|---|---|---|---|---|
| $0.124 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | ELJ-LC2R2MF | Manufacturer | Panasonic |
|---|---|---|---|
| Description | FIXED IND 2.2UH 520MA 330 MOHM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 173734 pcs | Data sheet | ELJ-PF, PE, PC, PA, PB, LC, LA Series |
| Category | Inductors, Coils, Chokes | Type | Wirewound |
| Tolerance | ±20% | Supplier Device Package | 1008 (2520 Metric) |
| Size / Dimension | 0.098" L x 0.079" W (2.50mm x 2.00mm) | Shielding | Unshielded |
| Series | LC | Ratings | - |
| Q @ Freq | - | Packaging | Cut Tape (CT) |
| Package / Case | 1008 (2520 Metric) | Other Names | P15205CT |
| Operating Temperature | -20°C ~ 85°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | Ferrite |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance Frequency - Test | 1MHz |
| Inductance | 2.2µH | Height - Seated (Max) | 0.071" (1.80mm) |
| Frequency - Self Resonant | - | Detailed Description | 2.2µH Unshielded Wirewound Inductor 520mA 330 mOhm 1008 (2520 Metric) |
| DC Resistance (DCR) | 330 mOhm | Current Rating | 520mA |
| Current - Saturation | 1.05A |
