Home > Products > RF/IF and RFID > Balun > EHF-2BG2060

EHF-2BG2060

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy EHF-2BG2060 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	EHF-2BG2060
Manufacturer	Panasonic
Description	BALUN 1.92-2.17GHZ 50/200 0805
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 4187 pcs
Reference Price (In US Dollars)	Get a quote

Product parameter
Data sheet

Product parameter

Part Number	EHF-2BG2060	Manufacturer	Panasonic
Description	BALUN 1.92-2.17GHZ 50/200 0805	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	4187 pcs	Data sheet	EHF-2BG2060
Category	RF/IF and RFID	Series	EHF
Return Loss (Min)	-	Phase Difference	180° ±15°
Packaging	Tape & Reel (TR)	Package / Case	0805 (2012 Metric)
Other Names	EHF2BG2060 P12038TR	Mounting Type	Surface Mount
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Insertion Loss (Max)	1.0dB	Impedance - Unbalanced/Balanced	50 / 200 Ohm
Frequency Range	1.92GHz ~ 2.17GHz	Detailed Description	RF Balun 1.92GHz ~ 2.17GHz 50 / 200 Ohm 0805 (2012 Metric)
