2SD21360QA
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 2SD21360QA with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 2SD21360QA with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 2SD21360QA |
|---|---|
| Manufacturer | Panasonic |
| Description | TRANS NPN 60V 3A MT-3 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 2SD21360QA | Manufacturer | Panasonic |
|---|---|---|---|
| Description | TRANS NPN 60V 3A MT-3 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4408 pcs | Data sheet | 2SD2136 Datasheet |
| Category | Discrete Semiconductor Products | Voltage - Collector Emitter Breakdown (Max) | 60V |
| Vce Saturation (Max) @ Ib, Ic | 1.2V @ 375mA, 3A | Transistor Type | NPN |
| Supplier Device Package | MT-3-A1 | Series | - |
| Power - Max | 1.5W | Packaging | Cut Tape (CT) |
| Package / Case | 3-SIP | Other Names | 2SD21360QACT |
| Operating Temperature | 150°C (TJ) | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Frequency - Transition | 220MHz | Detailed Description | Bipolar (BJT) Transistor NPN 60V 3A 220MHz 1.5W Through Hole MT-3-A1 |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 70 @ 1A, 4V | Current - Collector Cutoff (Max) | 300µA |
| Current - Collector (Ic) (Max) | 3A | Base Part Number | 2SD2136 |
