Home > Products > RF/IF and RFID > RF Transceiver Modules > NL-SW-EVDO-V

NL-SW-EVDO-V

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy NL-SW-EVDO-V with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	NL-SW-EVDO-V
Manufacturer	NimbeLink
Description	RF TXRX MODULE CELLULAR U.FL ANT
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 4397 pcs
Reference Price (In US Dollars)	Get a quote

Product parameter
Data sheet

Product parameter

Part Number	NL-SW-EVDO-V	Manufacturer	NimbeLink
Description	RF TXRX MODULE CELLULAR U.FL ANT	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	4397 pcs	Data sheet	Skywire™ 3G EVDO Brief Skywire™ EVDO 3G Datasheet
Category	RF/IF and RFID	Voltage - Supply	3.5 V ~ 4.3 V
Utilized IC / Part	-	Series	Skywire™
Serial Interfaces	UART, USB	Sensitivity	-
RF Family/Standard	Cellular	Protocol	CDMA, EV-DO
Power - Output	24.5dBm	Packaging	Bulk
Package / Case	20-DIP Module	Other Names	100013G 1477-1002 NIM-100013G
Operating Temperature	-40°C ~ 85°C	Mounting Type	Through Hole
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Modulation	-
Memory Size	-	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Frequency	800MHz, 1.9GHz	Data Rate	-
Current - Transmitting	750mA	Current - Receiving	750mA
Antenna Type	Not Included, U.FL
