Home > Products > Development Boards, Kits, Programmers > Evaluation Boards - DC/DC & AC/DC (Off-Line) S > SMPS1-01

SMPS1-01

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SMPS1-01 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	SMPS1-01
Manufacturer	NVE Corporation
Description	DEMO BOARD IL711/IL610 MSOP ISOL
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 463 pcs
Reference Price (In US Dollars)	4 pcs
Reference Price (In US Dollars)	$67.028

Product parameter
Data sheet

Product parameter

Part Number	SMPS1-01	Manufacturer	NVE Corporation
Description	DEMO BOARD IL711/IL610 MSOP ISOL	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	463 pcs	Data sheet	SMPS1-01
Category	Development Boards, Kits, Programmers	Voltage - Output	3.3V
Voltage - Input	11 V ~ 14 V	Utilized IC / Part	IL610, IL711
Supplied Contents	Board(s)	Series	IsoLoop®
Regulator Topology	Buck	Outputs and Type	1, Isolated
Other Names	390-1172	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	10 Weeks	Main Purpose	DC/DC, Step Down
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Frequency - Switching	130kHz
Detailed Description	IL610, IL711 IsoLoop® DC/DC, Step Down 1, Isolated Outputs Evaluation Board	Current - Output	750mA
Board Type	Fully Populated
