Home > Products > Switches > Pushbutton Switches > UB26SKW03N-A

UB26SKW03N-A

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy UB26SKW03N-A with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	UB26SKW03N-A
Manufacturer	NKK Switches
Description	SWITCH PUSHBUTTON DPDT 5A 125V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 9393 pcs
Reference Price (In US Dollars)	1 pcs
Reference Price (In US Dollars)	$3.368

Product parameter
Data sheet

Product parameter

Part Number	UB26SKW03N-A	Manufacturer	NKK Switches
Description	SWITCH PUSHBUTTON DPDT 5A 125V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	9393 pcs	Data sheet	UB Series Low Profile Pushbutton
Category	Switches	Voltage Rating - DC	30V
Voltage Rating - AC	125V	Type	Standard
Termination Style	PC Pin	Switch Function	On-On
Series	UB	Panel Cutout Dimensions	-
Packaging	Bulk	Operating Temperature	-20°C ~ 70°C
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Mechanical Life	200,000 Cycles	Manufacturer Standard Lead Time	11 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Ingress Protection	-
Illumination Voltage (Nominal)	-	Illumination Type, Color	-
Features	Epoxy Sealed Terminals	Electrical Life	10,000 Cycles
Detailed Description	Pushbutton Switch DPDT Standard Through Hole	Current Rating	5A (AC/DC)
Color - Actuator/Cap	Black	Circuit	DPDT
California Prop 65	Warning Information WARNING: This product can expose you to chemicals including Antimony oxide (Antimony trioxide) which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65warnings.ca.gov.	Actuator Type	Square, Button
