Home > Products > Switches > Pushbutton Switches > UB225SKG036B-3JB

UB225SKG036B-3JB

UB225SKG036B-3JB

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy UB225SKG036B-3JB with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	UB225SKG036B-3JB
Manufacturer	NKK Switches
Description	SWITCH PUSH DPDT 0.4VA 28V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	100 pcs	250 pcs	500 pcs
~~In Stock~~ 5925 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs
	$7.998	$7.886	$7.774	$7.21
	$7.098	$6.309	$6.084

Product parameter
Data sheet

Product parameter

Part Number	UB225SKG036B-3JB	Manufacturer	NKK Switches
Description	SWITCH PUSH DPDT 0.4VA 28V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	5925 pcs	Data sheet	UB2 Low Profile Pushbutton
Category	Switches	Voltage Rating - DC	28V
Voltage Rating - AC	28V	Type	Standard, Illuminated
Termination Style	PC Pin	Switch Function	On-Mom
Series	UB2	Panel Cutout Dimensions	-
Packaging	Bulk	Other Names	UB225SKG036B3JB
Operating Temperature	-25°C ~ 50°C	Mounting Type	Through Hole
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Mechanical Life	1,000,000 Cycles
Manufacturer Standard Lead Time	8 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Ingress Protection	-	Illumination Voltage (Nominal)	3.3 VDC
Illumination Type, Color	LED, White	Features	Epoxy Sealed Terminals
Electrical Life	200,000 Cycles	Detailed Description	Pushbutton Switch DPDT Standard, Illuminated Through Hole
Current Rating	0.4VA (AC/DC)	Color - Actuator/Cap	Clear (White Filter/Diffuser)
Circuit	DPDT	Actuator Type	Square, Button
