Home > Products > Switches > Pushbutton Switches > UB16NBKW015D

UB16NBKW015D

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy UB16NBKW015D with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	UB16NBKW015D
Manufacturer	NKK Switches
Description	SWITCH PUSHBUTTON SPDT 5A 125V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 10606 pcs
Reference Price (In US Dollars)	1 pcs
Reference Price (In US Dollars)	$3.725

Product parameter
Data sheet

Product parameter

Part Number	UB16NBKW015D	Manufacturer	NKK Switches
Description	SWITCH PUSHBUTTON SPDT 5A 125V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	10606 pcs	Data sheet	UB Series
Category	Switches	Voltage Rating - DC	30V
Voltage Rating - AC	125V	Type	Standard, Illuminated
Termination Style	Solder Lug	Switch Function	On-On
Series	UB	Panel Cutout Dimensions	Rectangular - 22.40mm x 16.20mm
Packaging	Bulk	Operating Temperature	-25°C ~ 50°C
Mounting Type	Panel Mount, Snap-In	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Mechanical Life	200,000 Cycles	Manufacturer Standard Lead Time	11 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Ingress Protection	-
Illumination Voltage (Nominal)	2 VDC	Illumination Type, Color	LED, Amber
Features	With Barrier	Electrical Life	10,000 Cycles
Detailed Description	Pushbutton Switch SPDT Standard, Illuminated Panel Mount, Snap-In	Current Rating	5A (AC/DC)
Color - Actuator/Cap	-	Circuit	SPDT
Actuator Type	Plunger for Cap
