Home > Products > Switches > Pushbutton Switches > UB15SKG036B

UB15SKG036B

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy UB15SKG036B with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	UB15SKG036B
Manufacturer	NKK Switches
Description	SWITCH PUSH SPDT 0.4VA 28V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	100 pcs	250 pcs	500 pcs
~~In Stock~~ 7489 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs
	$6.301	$6.214	$6.126	$5.689
	$5.601	$4.989	$4.814

Product parameter
Data sheet

Product parameter

Part Number	UB15SKG036B	Manufacturer	NKK Switches
Description	SWITCH PUSH SPDT 0.4VA 28V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	7489 pcs	Data sheet	UB Series
Category	Switches	Voltage Rating - DC	28V
Voltage Rating - AC	28V	Type	Standard, Illuminated
Termination Style	PC Pin	Switch Function	On-Mom
Series	UB	Panel Cutout Dimensions	-
Packaging	Bulk	Operating Temperature	-25°C ~ 50°C
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Mechanical Life	1,000,000 Cycles	Manufacturer Standard Lead Time	11 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Ingress Protection	-
Illumination Voltage (Nominal)	2.9 VDC	Illumination Type, Color	LED, White
Features	Epoxy Sealed Terminals	Electrical Life	200,000 Cycles
Detailed Description	Pushbutton Switch SPDT Standard, Illuminated Through Hole	Current Rating	0.4VA (AC/DC)
Color - Actuator/Cap	-	Circuit	SPDT
Actuator Type	Plunger for Cap
