Home > Products > Switches > Pushbutton Switches > GB15JVC

GB15JVC

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy GB15JVC with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	GB15JVC
Manufacturer	NKK Switches
Description	SWITCH PUSH SPDT 0.4VA 28V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	100 pcs	250 pcs	500 pcs	1000 pcs
~~In Stock~~ 19083 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs
	$2.546	$2.36	$2.298	$2.236
	$2.112	$2.05	$1.926	$1.739

Product parameter
Data sheet

Product parameter

Part Number	GB15JVC	Manufacturer	NKK Switches
Description	SWITCH PUSH SPDT 0.4VA 28V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	19083 pcs	Data sheet	GB Series Illuminated Plungers~
Category	Switches	Voltage Rating - DC	28V
Voltage Rating - AC	28V	Type	Standard, Illuminated
Termination Style	PC Pin	Switch Function	On-Mom
Series	GB	Panel Cutout Dimensions	-
Packaging	Tray	Other Names	GB15JVC-RO GB15JVC-RO-ND
Operating Temperature	-25°C ~ 55°C	Mounting Type	Through Hole, Right Angle, Vertical
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Mechanical Life	50,000 Cycles
Manufacturer Standard Lead Time	12 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Ingress Protection	-	Illumination Voltage (Nominal)	1.95 VDC
Illumination Type, Color	LED, Red	Features	-
Electrical Life	50,000 Cycles	Detailed Description	Pushbutton Switch SPDT Standard, Illuminated Through Hole, Right Angle, Vertical
Current Rating	0.4VA (AC/DC)	Color - Actuator/Cap	Clear
Circuit	SPDT	Actuator Type	Round, Plunger
