Home > Products > Switches > Toggle Switches > G12JVC

G12JVC

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy G12JVC with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	G12JVC
Manufacturer	NKK Switches
Description	SWITCH TOGGLE SPDT 0.4VA 28V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 14830 pcs
Reference Price (In US Dollars)	1 pcs
Reference Price (In US Dollars)	$2.356

Product parameter
Data sheet

Product parameter

Part Number	G12JVC	Manufacturer	NKK Switches
Description	SWITCH TOGGLE SPDT 0.4VA 28V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	14830 pcs	Data sheet	G Series Datasheet
Category	Switches	Voltage Rating - DC	28V
Voltage Rating - AC	28V	Termination Style	PC Pin
Switch Function	On-On	Series	G
Panel Cutout Dimensions	-	Packaging	Bulk
Other Names	360-1749 360-1749-ND 360-1764 G12JVC-RO	Operating Temperature	-25°C ~ 85°C
Mounting Type	Through Hole, Right Angle, Vertical	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	16 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Ingress Protection	-	Illumination Voltage (Nominal)	2 VDC
Illumination Type, Color	LED, Red	Illumination	Illuminated
Features	Process Sealed	Electrical Life	100,000 Cycles
Detailed Description	Toggle Switch SPDT Through Hole, Right Angle, Vertical	Current Rating	0.4VA (AC/DC)
Circuit	SPDT	Bushing Thread	Unthreaded
Actuator Type	Standard Round	Actuator Material	Polyamide (PA), Nylon, Glass Filled
Actuator Length	3.80mm
