B22EV
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy B22EV with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy B22EV with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | B22EV |
|---|---|
| Manufacturer | NKK Switches |
| Description | SWITCH TOGGLE DPDT 0.4VA 28V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $1.877 | $1.787 | $1.743 | $1.698 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $1.653 | $1.519 | $1.341 | $1.207 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | B22EV | Manufacturer | NKK Switches |
|---|---|---|---|
| Description | SWITCH TOGGLE DPDT 0.4VA 28V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 29017 pcs | Data sheet | B Series Toggle Datasheet |
| Category | Switches | Voltage Rating - DC | 28V |
| Voltage Rating - AC | 28V | Termination Style | PC Pin |
| Switch Function | On-On | Series | B |
| Panel Cutout Dimensions | - | Packaging | Bulk |
| Operating Temperature | -30°C ~ 85°C | Mounting Type | Through Hole, Right Angle, Vertical |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 10 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Ingress Protection | - |
| Illumination Voltage (Nominal) | - | Illumination Type, Color | - |
| Illumination | Non-Illuminated | Features | Epoxy Sealed Terminals |
| Electrical Life | 50,000 Cycles | Detailed Description | Toggle Switch DPDT Through Hole, Right Angle, Vertical |
| Current Rating | 0.4VA (AC/DC) | Circuit | DPDT |
| Bushing Thread | Unthreaded | Actuator Type | Flatted |
| Actuator Material | Brass, Nickel Plated | Actuator Length | 10.00mm |
