NDTD0505C
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy NDTD0505C with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy NDTD0505C with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | NDTD0505C |
|---|---|
| Manufacturer | Murata Power Solutions |
| Description | DC DC CONVERTER +/-5V 3W |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 5 pcs | 10 pcs | 25 pcs | |
|---|---|---|---|---|---|
| $6.382 | $6.353 | $6.307 | $6.235 | ||
| 50 pcs | 100 pcs | 250 pcs | 500 pcs | ||
| $6.081 | $5.773 | $5.408 | $5.039 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | NDTD0505C | Manufacturer | Murata Power Solutions |
|---|---|---|---|
| Description | DC DC CONVERTER +/-5V 3W | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 6856 pcs | Data sheet | NDTD Series Datasheet |
| Category | Power Supplies - Board Mount | Voltage - Output 3 | - |
| Voltage - Output 2 | -5V | Voltage - Output 1 | 5V |
| Voltage - Isolation | 1kV | Voltage - Input (Min) | 4.5V |
| Voltage - Input (Max) | 9V | Type | Isolated Module |
| Size / Dimension | 1.27" L x 0.58" W x 0.27" H (32.3mm x 14.7mm x 6.9mm) | Series | NDTD |
| Power (Watts) | 3W | Packaging | Tube |
| Package / Case | 24-DIP Module (600 mil, 8 Leads) | Other Names | 811-1368-5 |
| Operating Temperature | -40°C ~ 85°C | Number of Outputs | 2 |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 18 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Features | - | Efficiency | 72% |
| Detailed Description | Isolated Module DC DC Converter 2 Output 5V -5V 300mA, 300mA 4.5V - 9V Input | Current - Output (Max) | 300mA, 300mA |
| Applications | ITE (Commercial) |
