NDTD0503C
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy NDTD0503C with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy NDTD0503C with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | NDTD0503C |
|---|---|
| Manufacturer | Murata Power Solutions |
| Description | DC DC CONVERTER +/-3.3V 3W |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | NDTD0503C | Manufacturer | Murata Power Solutions |
|---|---|---|---|
| Description | DC DC CONVERTER +/-3.3V 3W | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4227 pcs | Data sheet | NDTD Series Datasheet |
| Category | Power Supplies - Board Mount | Voltage - Output 3 | - |
| Voltage - Output 2 | -3.3V | Voltage - Output 1 | 3.3V |
| Voltage - Isolation | 1kV | Voltage - Input (Min) | 4.5V |
| Voltage - Input (Max) | 9V | Type | Isolated Module |
| Size / Dimension | 1.27" L x 0.58" W x 0.27" H (32.3mm x 14.7mm x 6.9mm) | Series | NDTD |
| Power (Watts) | 3W | Packaging | Tube |
| Package / Case | 24-DIP Module (600 mil, 8 Leads) | Other Names | 811-1367-5 |
| Operating Temperature | -40°C ~ 85°C | Number of Outputs | 2 |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Features | - |
| Efficiency | 67% | Detailed Description | Isolated Module DC DC Converter 2 Output 3.3V -3.3V 454mA, 454mA 4.5V - 9V Input |
| Current - Output (Max) | 454mA, 454mA | Applications | ITE (Commercial) |
