55100C-R
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 55100C-R with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 55100C-R with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 55100C-R |
|---|---|
| Manufacturer | Murata Power Solutions |
| Description | CURR SENSE XFMR 1:1:100 15A SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 650 pcs | ||||
|---|---|---|---|---|---|
| $0.532 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 55100C-R | Manufacturer | Murata Power Solutions |
|---|---|---|---|
| Description | CURR SENSE XFMR 1:1:100 15A SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 63595 pcs | Data sheet | 5500 Series |
| Category | Transformers | Weight | 0.004 lb (1.70g) |
| Type | Invasive | Turns Ratio - Primary:Secondary | 1:1:100 |
| Termination Style | - | Size / Dimension | 0.575" L x 0.496" W (14.60mm x 12.60mm) |
| Series | 5500 | Ratings | - |
| Packaging | Tape & Reel (TR) | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 8 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance | 14.8mH |
| Height - Seated (Max) | 0.280" (7.10mm) | Frequency Range | 50kHz ~ 500kHz |
| Energy Time (E.T.) | - | Detailed Description | 15A 1:1:100 Current Sense Transformer 50kHz ~ 500kHz 2.3 mOhm Primary, 850 mOhm Secondary 14.8mH Surface Mount |
| DC Resistance (DCR) | 2.3 mOhm Primary, 850 mOhm Secondary | Current Ratio | - |
| Current Rating | 15A |
