NFL18SP307X1A3D
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy NFL18SP307X1A3D with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy NFL18SP307X1A3D with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | NFL18SP307X1A3D |
|---|---|
| Manufacturer | Murata Electronics |
| Description | FILTER LC(PI) 60NH/19PF SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 4000 pcs | ||||
|---|---|---|---|---|---|
| $0.059 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | NFL18SP307X1A3D | Manufacturer | Murata Electronics |
|---|---|---|---|
| Description | FILTER LC(PI) 60NH/19PF SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 385260 pcs | Data sheet | NFL18SPyyyX1A3y Spec |
| Category | Filters | Voltage - Rated | 10V |
| Values | L = 60nH, C = 19pF | Type | Low Pass |
| Technology | LC (Pi) | Size / Dimension | 0.063" L x 0.032" W (1.60mm x 0.80mm) |
| Series | EMIFIL®, NFL18 | Resistance - Channel (Ohms) | - |
| Packaging | Tape & Reel (TR) | Package / Case | 0603 (1608 Metric), 3 PC Pad |
| Operating Temperature | -55°C ~ 125°C | Number of Channels | 1 |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 7 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height | 0.028" (0.70mm) | Filter Order | 3rd |
| ESD Protection | No | Detailed Description | LC (Pi) EMI Filter 3rd Order Low Pass 1 Channel L = 60nH, C = 19pF 100mA 0603 (1608 Metric), 3 PC Pad |
| Current | 100mA | Center / Cutoff Frequency | 300MHz (Cutoff) |
| Attenuation Value | - | Applications | General Purpose |
