2506-2-00-80-00-00-07-0
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 2506-2-00-80-00-00-07-0 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 2506-2-00-80-00-00-07-0 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 2506-2-00-80-00-00-07-0 |
|---|---|
| Manufacturer | Mill-Max |
| Description | TERM TURRET SNG |
| Lead Free Status / RoHS Status | RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $0.319 | $0.281 | $0.264 | $0.253 | $0.242 | |
| 250 pcs | 500 pcs | 1000 pcs | 2500 pcs | ||
| $0.22 | $0.198 | $0.176 | $0.16 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 2506-2-00-80-00-00-07-0 | Manufacturer | Mill-Max |
|---|---|---|---|
| Description | TERM TURRET SNG | Lead Free Status / RoHS Status | RoHS Compliant |
| Quantity Available | 146806 pcs | Data sheet | Solder Terminal Turrets (metric)Solder Terminal Turrets (in.) |
| Category | Connectors, Interconnects | Termination | Swage |
| Terminal Type | Single End | Staking Side OD | 0.062" (1.57mm) |
| Staking Side ID | 0.043" (1.09mm) | Series | 2506 |
| RoHS Status | RoHS Compliant | Other Names | 2506-2-00-80-00-00-07-0-ND ED11396 |
| Number of Turrets | Single | Mounting Type | Through Hole |
| Mounting Hole Diameter | 0.067" (1.70mm) | Material - Insulation | - |
| Manufacturer Standard Lead Time | 5 Weeks | Length - Overall | 0.240" (6.10mm) |
| Length - Below Flange | 0.084" (2.13mm) | Length - Above Board | 0.156" (3.96mm) |
| Insulation Color | - | Insulation | Non-Insulated |
| Flange Diameter | 0.125" (3.18mm) | Diameter - Turret Head | 0.093" (2.36mm) |
| Detailed Description | Terminal Turret Connector Single End 0.156" (3.96mm) Tin | Contact Material | Brass Alloy |
| Contact Finish Thickness | 200.0µin (5.08µm) | Contact Finish | Tin |
| Board Thickness | 0.062" (1.57mm) |
