Home > Products > Transformers > Switching Converter, SMPS Transformers > 760390015

760390015

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 760390015 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	760390015
Manufacturer	Midcom / Wurth Electronics
Description	TRANSFORMER 475UH SMD
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 75696 pcs
Reference Price (In US Dollars)	1200 pcs
Reference Price (In US Dollars)	$0.419

Product parameter
Data sheet

Product parameter

Part Number	760390015	Manufacturer	Midcom / Wurth Electronics
Description	TRANSFORMER 475UH SMD	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	75696 pcs	Data sheet	760390015 Drawing
Category	Transformers	Voltage - Primary	-
Voltage - Isolation	3125Vrms	Voltage - Auxiliary	-
Type	For DC/DC Converters	Size / Dimension	0.265" L x 0.281" W (6.73mm x 7.14mm)
Series	WE-PP, MID-PPTI	Packaging	Tape & Reel (TR)
Other Names	732-4459-2	Operating Temperature	-40°C ~ 125°C
Mounting Type	Surface Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	18 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Intended Chipset	SN6501	Inductance @ Frequency	475µH @ 10kHz
Height - Seated (Max)	0.170" (4.32mm)	Frequency	10kHz
Footprint	0.265" L x 0.395" W (6.73mm x 10.05mm)	Chipset Manufacturer	Texas Instruments
Applications	Forward, Push-Pull Converters
