760390014
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 760390014 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 760390014 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 760390014 |
|---|---|
| Manufacturer | Midcom / Wurth Electronics |
| Description | TRANSFORMER 475UH SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 50 pcs | 100 pcs | 500 pcs |
|---|---|---|---|---|---|
| $0.672 | $0.604 | $0.548 | $0.502 | $0.474 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | 760390014 | Manufacturer | Midcom / Wurth Electronics |
|---|---|---|---|
| Description | TRANSFORMER 475UH SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 66641 pcs | Data sheet | 760390014 Drawing |
| Category | Transformers | Voltage - Primary | - |
| Voltage - Isolation | 3125Vrms | Voltage - Auxiliary | - |
| Type | For DC/DC Converters | Size / Dimension | 0.265" L x 0.281" W (6.73mm x 7.14mm) |
| Series | WE-PP, MID-PPTI | Packaging | Cut Tape (CT) |
| Other Names | 732-4458-1 | Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 18 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Intended Chipset | SN6501 | Inductance @ Frequency | 475µH @ 10kHz |
| Height - Seated (Max) | 0.170" (4.32mm) | Frequency | 10kHz |
| Footprint | 0.265" L x 0.395" W (6.73mm x 10.05mm) | Chipset Manufacturer | Texas Instruments |
| Applications | Forward, Push-Pull Converters |
