Home > Products > Discrete Semiconductor Products > Diodes - Rectifiers - Single > UPS5100HE3

UPS5100HE3

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy UPS5100HE3 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	UPS5100HE3
Manufacturer	Microsemi
Description	DIODE SCHOTTKY 100V 5A POWERMITE
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 108890 pcs
Reference Price (In US Dollars)	5000 pcs
Reference Price (In US Dollars)	$0.173

Product parameter

Product parameter

Part Number	UPS5100HE3	Manufacturer	Microsemi
Description	DIODE SCHOTTKY 100V 5A POWERMITE	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	108890 pcs	Data sheet
Category	Discrete Semiconductor Products	Voltage - Forward (Vf) (Max) @ If	810mV @ 5A
Voltage - DC Reverse (Vr) (Max)	100V	Supplier Device Package	Powermite 3
Speed	Fast Recovery = 200mA (Io)	Series	-
Packaging	Tape & Reel (TR)	Package / Case	Powermite®3
Other Names	UPS5100HE3/TR13 UPS5100HE3TR	Operating Temperature - Junction	-55°C ~ 125°C
Mounting Type	Surface Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Diode Type	Schottky
Detailed Description	Diode Schottky 100V 5A Surface Mount Powermite 3	Current - Reverse Leakage @ Vr	200µA @ 100V
Current - Average Rectified (Io)	5A	Capacitance @ Vr, F	150pF @ 4V, 1MHz
Base Part Number	UPS5100
