JANS1N5809
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy JANS1N5809 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy JANS1N5809 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | JANS1N5809 |
|---|---|
| Manufacturer | Microsemi |
| Description | DIODE GEN PURP 100V 3A AXIAL |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | |||
|---|---|---|---|---|---|
| $26.054 | $24.474 | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | JANS1N5809 | Manufacturer | Microsemi |
|---|---|---|---|
| Description | DIODE GEN PURP 100V 3A AXIAL | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 1479 pcs | Data sheet | 1N5807,9,11 |
| Category | Discrete Semiconductor Products | Voltage - Forward (Vf) (Max) @ If | 875mV @ 4A |
| Voltage - DC Reverse (Vr) (Max) | 100V | Speed | Fast Recovery = 200mA (Io) |
| Series | Military, MIL-PRF-19500/477 | Reverse Recovery Time (trr) | 30ns |
| Packaging | Bulk | Package / Case | B, Axial |
| Other Names | 1086-15145 1086-15145-MIL |
Operating Temperature - Junction | -65°C ~ 175°C |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | Diode Type | Standard |
| Detailed Description | Diode Standard 100V 3A Through Hole | Current - Reverse Leakage @ Vr | 5µA @ 100V |
| Current - Average Rectified (Io) | 3A | Capacitance @ Vr, F | 60pF @ 10V, 1MHz |
