APT20N60SC3G
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy APT20N60SC3G with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy APT20N60SC3G with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | APT20N60SC3G |
|---|---|
| Manufacturer | Microsemi |
| Description | MOSFET N-CH 600V 20.7A D3PAK |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | APT20N60SC3G | Manufacturer | Microsemi |
|---|---|---|---|
| Description | MOSFET N-CH 600V 20.7A D3PAK | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4052 pcs | Data sheet | APT20N60(B,S)C3 |
| Category | Discrete Semiconductor Products | Vgs(th) (Max) @ Id | 3.9V @ 1mA |
| Vgs (Max) | ±20V | Technology | MOSFET (Metal Oxide) |
| Supplier Device Package | D3Pak | Series | CoolMOS™ |
| Rds On (Max) @ Id, Vgs | 190 mOhm @ 13.1A, 10V | Power Dissipation (Max) | 208W (Tc) |
| Packaging | Tube | Package / Case | TO-268-3, D³Pak (2 Leads + Tab), TO-268AA |
| Operating Temperature | -55°C ~ 150°C (TJ) | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Input Capacitance (Ciss) (Max) @ Vds | 2440pF @ 25V | Gate Charge (Qg) (Max) @ Vgs | 114nC @ 10V |
| FET Type | N-Channel | FET Feature | - |
| Drive Voltage (Max Rds On, Min Rds On) | 10V | Drain to Source Voltage (Vdss) | 600V |
| Detailed Description | N-Channel 600V 20.7A (Tc) 208W (Tc) Surface Mount D3Pak | Current - Continuous Drain (Id) @ 25°C | 20.7A (Tc) |
