2N3700UB
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 2N3700UB with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 2N3700UB with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 2N3700UB |
|---|---|
| Manufacturer | Microsemi |
| Description | TRANS NPN 80V 1A UB |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 100 pcs | 250 pcs |
|---|---|---|---|---|---|
| $6.672 | $6.067 | $5.612 | $5.157 | $4.702 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | 2N3700UB | Manufacturer | Microsemi |
|---|---|---|---|
| Description | TRANS NPN 80V 1A UB | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 7739 pcs | Data sheet | 2N3700UB |
| Category | Discrete Semiconductor Products | Voltage - Collector Emitter Breakdown (Max) | 80V |
| Vce Saturation (Max) @ Ib, Ic | 500mV @ 50mA, 500mA | Transistor Type | NPN |
| Supplier Device Package | UB | Series | - |
| Power - Max | 500mW | Packaging | Bulk |
| Package / Case | 3-SMD, No Lead | Operating Temperature | -65°C ~ 200°C (TJ) |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 8 Weeks | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Frequency - Transition | - | Detailed Description | Bipolar (BJT) Transistor NPN 80V 1A 500mW Surface Mount UB |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 50 @ 500mA, 10V | Current - Collector Cutoff (Max) | 10µA (ICBO) |
| Current - Collector (Ic) (Max) | 1A |
