PM20C05VBDN
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PM20C05VBDN with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PM20C05VBDN with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | PM20C05VBDN |
|---|---|
| Manufacturer | METZ CONNECT |
| Description | PIN HEADER, SMT, DUAL ROW, 2.00 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | 500 pcs | |
|---|---|---|---|---|---|
| $0.314 | $0.277 | $0.239 | $0.195 | ||
| 1000 pcs | 5000 pcs | 10000 pcs | |||
| $0.174 | $0.152 | $0.144 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | PM20C05VBDN | Manufacturer | METZ CONNECT |
|---|---|---|---|
| Description | PIN HEADER, SMT, DUAL ROW, 2.00 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 163187 pcs | Data sheet | PM20CxxVBDN Datasheet |
| Category | Connectors, Interconnects | Voltage Rating | - |
| Termination | Solder | Style | Board to Board |
| Shrouding | Unshrouded | Series | - |
| Row Spacing - Mating | 0.079" (2.00mm) | Pitch - Mating | 0.079" (2.00mm) |
| Packaging | Bulk | Overall Contact Length | - |
| Other Names | 1849-1015 1849-1015-2 1849-1015-2-ND |
Operating Temperature | -40°C ~ 105°C |
| Number of Rows | 2 | Number of Positions Loaded | All |
| Number of Positions | 10 | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | - |
| Mated Stacking Heights | - | Manufacturer Standard Lead Time | 9 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insulation Material | Polyethylene |
| Insulation Height | 0.079" (2.00mm) | Insulation Color | Black |
| Ingress Protection | - | Features | - |
| Fastening Type | Push-Pull | Detailed Description | Connector Header Surface Mount 10 position 0.079" (2.00mm) |
| Current Rating | 1A | Contact Type | Male Pin |
| Contact Shape | Square | Contact Material | Copper Zinc |
| Contact Length - Post | - | Contact Length - Mating | 0.157" (4.00mm) |
| Contact Finish Thickness - Post | - | Contact Finish Thickness - Mating | Flash |
| Contact Finish - Post | - | Contact Finish - Mating | Gold |
| Connector Type | Header | Applications | - |
