CAF94505
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy CAF94505 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy CAF94505 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | CAF94505 |
|---|---|
| Manufacturer | Laird Technologies - Antennas |
| Description | RF ANT 2.4GHZ/5.3GHZ PCB TRACE |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 100 pcs | |
|---|---|---|---|---|---|
| $1.759 | $1.57 | $1.413 | $1.287 | ||
| 250 pcs | 500 pcs | 1000 pcs | 2500 pcs | ||
| $1.162 | $1.042 | $0.879 | $0.835 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | CAF94505 | Manufacturer | Laird Technologies - Antennas |
|---|---|---|---|
| Description | RF ANT 2.4GHZ/5.3GHZ PCB TRACE | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 38813 pcs | Data sheet | CAF94504/05 Nanoblade DatasheetNanoblade Series Drawing |
| Category | RF/IF and RFID | VSWR | 2 |
| Termination | Cable (100mm) - IPEX MHF | Series | NanoBlade |
| Return Loss | - | Packaging | Bulk |
| Other Names | 994-1009 | Number of Bands | 3 |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 8 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Ingress Protection | - | Height (Max) | 0.650" (16.50mm) |
| Gain | 2dBi, 3.9dBi, 4dBi | Frequency Range | 2.4GHz ~ 2.5GHz, 4.9GHz ~ 6GHz |
| Frequency Group | UHF (2 GHz ~ 3 GHz), SHF (f > 4 GHz) | Frequency (Center/Band) | 2.4GHz, 5.3GHz, 5.6GHz |
| Features | - | Detailed Description | 2.4GHz, 5.3GHz, 5.6GHz Bluetooth, Wi-Fi, WiMax™ PCB Trace RF Antenna 2.4GHz ~ 2.5GHz, 4.9GHz ~ 6GHz 2dBi, 3.9dBi, 4dBi Cable (100mm) - IPEX MHF Surface Mount |
| Applications | Bluetooth, Wi-Fi, WiMax™ | Antenna Type | PCB Trace |
