CAF94504
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy CAF94504 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy CAF94504 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | CAF94504 |
|---|---|
| Manufacturer | Laird Technologies - Antennas |
| Description | RF ANT 2.4GHZ/5.3GHZ PCB TRACE |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 100 pcs | |
|---|---|---|---|---|---|
| $2.513 | $2.245 | $2.021 | $1.841 | ||
| 250 pcs | 500 pcs | 1000 pcs | 2500 pcs | ||
| $1.661 | $1.491 | $1.257 | $1.194 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | CAF94504 | Manufacturer | Laird Technologies - Antennas |
|---|---|---|---|
| Description | RF ANT 2.4GHZ/5.3GHZ PCB TRACE | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 29666 pcs | Data sheet | CAF94504/05 Nanoblade DatasheetNanoblade Series Drawing |
| Category | RF/IF and RFID | VSWR | 2 |
| Termination | Cable (100mm) - MMCX | Series | NanoBlade |
| Return Loss | - | Packaging | Bulk |
| Other Names | 994-1008 | Number of Bands | 3 |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Ingress Protection | - |
| Height (Max) | 0.650" (16.50mm) | Gain | 2dBi, 3.9dBi, 4dBi |
| Frequency Range | 2.4GHz ~ 2.5GHz, 4.9GHz ~ 6GHz | Frequency Group | UHF (2 GHz ~ 3 GHz), SHF (f > 4 GHz) |
| Frequency (Center/Band) | 2.4GHz, 5.3GHz, 5.6GHz | Features | - |
| Detailed Description | 2.4GHz, 5.3GHz, 5.6GHz Bluetooth, Wi-Fi, WiMax™ PCB Trace RF Antenna 2.4GHz ~ 2.5GHz, 4.9GHz ~ 6GHz 2dBi, 3.9dBi, 4dBi Cable (100mm) - MMCX Surface Mount | Applications | Bluetooth, Wi-Fi, WiMax™ |
| Antenna Type | PCB Trace |
