Home > Products > Development Boards, Kits, Programmers > Evaluation Boards - DC/DC & AC/DC (Off-Line) S > ISL78233EVAL1Z

ISL78233EVAL1Z

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ISL78233EVAL1Z with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	ISL78233EVAL1Z
Manufacturer	Intersil
Description	EVAL BOARD FOR ISL78233
Lead Free Status / RoHS Status	Not applicable / Not applicable

~~In Stock~~ 1600 pcs
Reference Price (In US Dollars)	1 pcs
Reference Price (In US Dollars)	$23.19

Product parameter
Data sheet

Product parameter

Part Number	ISL78233EVAL1Z	Manufacturer	Intersil
Description	EVAL BOARD FOR ISL78233	Lead Free Status / RoHS Status	Not applicable / Not applicable
Quantity Available	1600 pcs	Data sheet	ISL78233, ISL78234 Datasheet ISL7823xEVAL1Z User Guide
Category	Development Boards, Kits, Programmers	Voltage - Output	1.8V
Voltage - Input	2.7 V ~ 5.5 V	Utilized IC / Part	ISL78233
Supplied Contents	Board(s)	Series	-
Regulator Topology	Buck	Outputs and Type	1, Non-Isolated
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Manufacturer Standard Lead Time	9 Weeks
Main Purpose	DC/DC, Step Down	Lead Free Status / RoHS Status	Not applicable / Not applicable
Frequency - Switching	2MHz	Detailed Description	ISL78233 - DC/DC, Step Down 1, Non-Isolated Outputs Evaluation Board
Current - Output	4A	Board Type	Fully Populated
