FS25R12W1T4BOMA1
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy FS25R12W1T4BOMA1 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy FS25R12W1T4BOMA1 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | FS25R12W1T4BOMA1 |
|---|---|
| Manufacturer | International Rectifier (Infineon Technologies) |
| Description | IGBT MODULE 1200V 25A |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | |||
|---|---|---|---|---|---|
| $13.813 | $12.74 | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | FS25R12W1T4BOMA1 | Manufacturer | International Rectifier (Infineon Technologies) |
|---|---|---|---|
| Description | IGBT MODULE 1200V 25A | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 2417 pcs | Data sheet | FS25R12W1T4 |
| Category | Discrete Semiconductor Products | Voltage - Collector Emitter Breakdown (Max) | 1200V |
| Vce(on) (Max) @ Vge, Ic | 2.25V @ 15V, 25A | Supplier Device Package | Module |
| Series | - | Power - Max | 205W |
| Package / Case | Module | Other Names | FS25R12W1T4 FS25R12W1T4-ND SP000255353 |
| Operating Temperature | -40°C ~ 150°C (TJ) | NTC Thermistor | Yes |
| Mounting Type | Chassis Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Input Capacitance (Cies) @ Vce | 1.45nF @ 25V |
| Input | Standard | IGBT Type | Trench Field Stop |
| Detailed Description | IGBT Module Trench Field Stop Three Phase Inverter 1200V 45A 205W Chassis Mount Module | Current - Collector Cutoff (Max) | 1mA |
| Current - Collector (Ic) (Max) | 45A | Configuration | Three Phase Inverter |
