Home > Products > Capacitors > Aluminum Electrolytic Capacitors > 226TTA100M

226TTA100M

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 226TTA100M with confidence from Components-World.HK, 1 Year Warranty

Dowload 226TTA100M Details in PDF

Request a Quote

Part Number	226TTA100M
Manufacturer	Illinois Capacitor
Description	AXIAL E-CAP
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	1000 pcs	2500 pcs	5000 pcs
~~In Stock~~ 295035 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	100 pcs	500 pcs
	$0.273	$0.202	$0.138	$0.11
	$0.092	$0.087	$0.081

Product parameter
Data sheet

Product parameter

Part Number	226TTA100M	Manufacturer	Illinois Capacitor
Description	AXIAL E-CAP	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	295035 pcs	Data sheet	TTA Series Datasheet
Category	Capacitors	Voltage - Rated	100V
Tolerance	±20%	Surface Mount Land Size	-
Size / Dimension	0.315" Dia x 0.630" L (8.00mm x 16.00mm)	Series	TTA
Ripple Current @ Low Frequency	120mA @ 120Hz	Ripple Current @ High Frequency	183.6mA @ 50kHz
Ratings	-	Polarization	Polar
Packaging	Bulk	Package / Case	Axial, Can
Other Names	1572-1095	Operating Temperature	-40°C ~ 85°C
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	22 Weeks	Lifetime @ Temp.	2000 Hrs @ 85°C
Lead Spacing	-	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Height - Seated (Max)	-	ESR (Equivalent Series Resistance)	15.072 Ohm @ 120Hz
Detailed Description	22µF 100V Aluminum Electrolytic Capacitors Axial, Can 15.072 Ohm @ 120Hz 2000 Hrs @ 85°C	Capacitance	22µF
Applications	General Purpose
