Home > Products > Capacitors > Aluminum Electrolytic Capacitors > 226TTA035MSD

226TTA035MSD

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 226TTA035MSD with confidence from Components-World.HK, 1 Year Warranty

Dowload 226TTA035MSD Details in PDF

Request a Quote

Part Number	226TTA035MSD
Manufacturer	Illinois Capacitor
Description	CAP ALUM 22UF 35V 20% AXIAL
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 170310 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	100 pcs	500 pcs
Reference Price (In US Dollars)	$0.276	$0.204	$0.14	$0.111

Product parameter
Data sheet

Product parameter

Part Number	226TTA035MSD	Manufacturer	Illinois Capacitor
Description	CAP ALUM 22UF 35V 20% AXIAL	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	170310 pcs	Data sheet	TTA Series Datasheet Special Order Indicators
Category	Capacitors	Voltage - Rated	35V
Tolerance	±20%	Surface Mount Land Size	-
Size / Dimension	0.197" Dia x 0.512" L (5.00mm x 13.00mm)	Series	TTA
Ripple Current @ Low Frequency	70mA @ 120Hz	Ripple Current @ High Frequency	107.1mA @ 50kHz
Ratings	-	Polarization	Polar
Packaging	Cut Tape (CT)	Package / Case	Axial, Can
Other Names	1572-1248-1	Operating Temperature	-40°C ~ 85°C
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	Not Applicable
Manufacturer Standard Lead Time	22 Weeks	Lifetime @ Temp.	2000 Hrs @ 85°C
Lead Spacing	-	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Height - Seated (Max)	-	ESR (Equivalent Series Resistance)	10.55 Ohm @ 120Hz
Detailed Description	22µF 35V Aluminum Electrolytic Capacitors Axial, Can 10.55 Ohm @ 120Hz 2000 Hrs @ 85°C	Capacitance	22µF
Applications	General Purpose
