MMIX1X200N60B3H1
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy MMIX1X200N60B3H1 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy MMIX1X200N60B3H1 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | MMIX1X200N60B3H1 |
|---|---|
| Manufacturer | IXYS Corporation |
| Description | IGBT 600V 175A 520W SMPD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 20 pcs | 40 pcs | 100 pcs | |
|---|---|---|---|---|---|
| $13.54 | $12.525 | $11.51 | $10.697 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | MMIX1X200N60B3H1 | Manufacturer | IXYS Corporation |
|---|---|---|---|
| Description | IGBT 600V 175A 520W SMPD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 2818 pcs | Data sheet | MMIX1X200N60B3H1 |
| Category | Discrete Semiconductor Products | Voltage - Collector Emitter Breakdown (Max) | 600V |
| Vce(on) (Max) @ Vge, Ic | 1.7V @ 15V, 100A | Test Condition | 360V, 100A, 1 Ohm, 15V |
| Td (on/off) @ 25°C | 48ns/160ns | Switching Energy | 2.85mJ (on), 2.9mJ (off) |
| Supplier Device Package | 24-SMPD | Series | GenX3™, XPT™ |
| Reverse Recovery Time (trr) | 100ns | Power - Max | 520W |
| Packaging | Tube | Package / Case | 24-PowerSMD, 21 Leads |
| Operating Temperature | -55°C ~ 150°C (TJ) | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Input Type | Standard | IGBT Type | - |
| Gate Charge | 315nC | Detailed Description | IGBT 600V 175A 520W Surface Mount 24-SMPD |
| Current - Collector Pulsed (Icm) | 1000A | Current - Collector (Ic) (Max) | 175A |
| Base Part Number | IXG*200N60 |
