Home > Products > Switches > Snap Action, Limit Switches > ZW50F15AD1

ZW50F15AD1

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ZW50F15AD1 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	ZW50F15AD1
Manufacturer	Honeywell Sensing and Productivity Solutions
Description	SWITCH SNAP ACTION SPDT 5A 125V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	100 pcs	250 pcs	500 pcs	1000 pcs
~~In Stock~~ 17171 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs
	$3.473	$2.542	$2.38	$2.247
	$2.106	$2.015	$1.936	$1.844

Product parameter
Data sheet

Product parameter

Part Number	ZW50F15AD1	Manufacturer	Honeywell Sensing and Productivity Solutions
Description	SWITCH SNAP ACTION SPDT 5A 125V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	17171 pcs	Data sheet	Basic, Toggle, Rocker Switches Range Guide Basic Switches Line Guide ZW Series Datasheet Z Series Install Instr
Category	Switches	Voltage Rating - AC	125V
Termination Style	Solder Lug	Switch Function	On-Mom
Series	ZW	Release Force	50gf
Pretravel	0.047" (1.2mm)	Packaging	Bulk
Overtravel	0.025" (0.6mm)	Other Names	480-2357
Operating Temperature	-40°C ~ 120°C	Operating Position	0.330" (8.4mm)
Operating Force	203gf	Mounting Type	Chassis Mount
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Mechanical Life	2,000,000 Cycles
Manufacturer Standard Lead Time	10 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Ingress Protection	IP00	Features	-
Electrical Life	10,000 Cycles	Differential Travel	0.008" (0.2mm)
Current Rating	5A (AC)	Circuit	SPDT
Actuator Type	Round (Pin Plunger)
