Home > Products > Switches > Snap Action, Limit Switches > BAF1-3RNX1

BAF1-3RNX1

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy BAF1-3RNX1 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	BAF1-3RNX1
Manufacturer	Honeywell Sensing and Productivity Solutions
Description	SWITCH SNAP ACTION SPDT 20A 125V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 474 pcs
Reference Price (In US Dollars)	3 pcs
Reference Price (In US Dollars)	$73.045

Product parameter
Data sheet

Product parameter

Part Number	BAF1-3RNX1	Manufacturer	Honeywell Sensing and Productivity Solutions
Description	SWITCH SNAP ACTION SPDT 20A 125V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	474 pcs	Data sheet	BZ,BA,BM,6AS,W,Y Series
Category	Switches	Voltage Rating - DC	125V
Voltage Rating - AC	125V	Termination Style	Screw Terminal
Switch Function	On-On	Series	BAF1
Release Force	-	Pretravel	0.094" (2.4mm)
Packaging	Bulk	Overtravel	0.219" (5.6mm)
Other Names	480-4525 BAF1-3RNX1-ND BAF13RNX1	Operating Temperature	-32°C ~ 71°C
Operating Position	2.094" (53.2mm)	Operating Force	794gf
Mounting Type	Chassis Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Mechanical Life	-	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Ingress Protection	-	Features	Reset Plunger on Bottom
Electrical Life	-	Differential Travel	-
Current Rating	20A (AC), 500mA (DC)	Circuit	SPDT
Actuator Type	Round (Pin Plunger)
