Home > Products > Switches > Snap Action, Limit Switches > BAF1-2RQ9-RH

BAF1-2RQ9-RH

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy BAF1-2RQ9-RH with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	BAF1-2RQ9-RH
Manufacturer	Honeywell Sensing and Productivity Solutions
Description	SWITCH SNAP ACTION SPDT 20A 125V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 447 pcs
Reference Price (In US Dollars)	3 pcs
Reference Price (In US Dollars)	$69.138

Product parameter
Data sheet

Product parameter

Part Number	BAF1-2RQ9-RH	Manufacturer	Honeywell Sensing and Productivity Solutions
Description	SWITCH SNAP ACTION SPDT 20A 125V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	447 pcs	Data sheet	BZ,BA,BM,6AS,W,Y Series
Category	Switches	Voltage Rating - DC	125V
Voltage Rating - AC	125V	Termination Style	Screw Terminal
Switch Function	On-Mom	Series	BAF1
Release Force	340gf	Pretravel	0.094" (2.4mm)
Packaging	Bulk	Overtravel	0.156" (3.96mm)
Other Names	480-4522 BAF1-2RQ9-RH-ND BAF12RQ9RH	Operating Temperature	-32°C ~ 71°C
Operating Position	2.547" (64.7mm)	Operating Force	1134gf
Mounting Type	Chassis Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Mechanical Life	-	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Ingress Protection	-	Features	Actuator Mounted Right Side
Electrical Life	-	Differential Travel	0.010" (0.25mm)
Current Rating	20A (AC), 500mA (DC)	Circuit	SPDT
Actuator Type	Roller Plunger
